Single Row Radial Needle Roller Bearing K 10X13X10 TN Polymide Cage

  • 1
  • 2

Brand Name : MOUETTE

Model Number : K 4X7X7 TN, K 6X9X8 TN, K 8X12X10 TN, K 10X13X10TN, K 10X14X13 TN, K 12X16X13 TN

Certification : ISO/TS 16949:2009, ISO 9001:2008

Place of Origin : China

MOQ : 100

Price : USD0.4 per Piece

Payment Terms : L/C, T/T, D/A, Western Union, Paypal

Supply Ability : 500,000 Pieces per Month.

Delivery Time : 3-45 working days.(Huge Quantity Stocks Available))

Packaging Details : Plastic bags, Cartons and European Standard Plywood Case.

Name : Needle Roller And Cage Assemblies

Basic Product Description : Single row needle roller and cage assembly

Seals : No Seal

Clearance : Normal Clearance (CN)

Cage material : Polymide / Steel

Bearing Material : Bearing steel

Number of Rows of Rollers : Single Row

Inch - Metric : Metric

Component : Roller Assembly Only

Customized : Standard or Customized are Available

Contact Now

Single Row Radial Needle Roller And Cage Assemblies K 10X13X10 TN



Needle roller and cage assemblies are self-contained, ready-to-mount bearings without inner and outer rings. In applications where the shaft and housing bore can serve as raceways, the assemblies can be used to create bearing arrangements that require minimal radial space. As the clearance of the bearing arrangement is only affected by the roller sorting and the finish of shaft and housing, very precise bearing arrangements can be achieved.

Features and benefits

  • Lowest cross section among rolling bearings
    In applications where less space is available, needle roller and cage assemblies offer a very compact solution.
  • High load carrying capacity
    Owing to their large number of rollers, needle roller and cage assemblies have a high load carrying capacity.
  • High stiffness
    Because of their large number of small-diameter rollers, needle roller and cage assemblies have high stiffness.
  • Accommodate axial displacement in both directions



Single Row Radial Needle Roller And Cage Assemblies Specifications:

Shaft

Diameter

 Bearing Designation

Mass

Approx

 Boundary Dimensions Basic Load Rating Limiting Speed
Current Code Original Code Fw D C Dynamic Static Oil
mm g mm N rpm
3 K 3X5X7 TN   0.3 3 5 7 1.54 1.29 50000
K 3X5X9 TN   0.4 3 5 9 1.71 1.48
K 3X6X7 TN   0.4 3 6 7 1.43 0.97 47000
4 K 4X7X7 TN   0.5 4 7 7 2.33 1.84 43000
K 4X7X10 TN   0.7 4 7 10 2.35 1.92 39000
5 K 5X8X8 TN 29241/5 0.7 5 8 8 2300 1880 37000
K 5X8X10 TN 39241/5 0.9 5 8 10 2800 2450 37000
6 K 6X9X8 TN 29241/6 0.8 6 9 8 25600 2240 35000
K 6X9X10 TN 39241/6 1 6 9 10 3300 3100 35000
K 6X10X13 TN 19241/6 1.3 6 10 13 3500 2800 33000
7 K 7X10X8T N 29241/7 0.9 7 10 8 2750 2550 32000
K 7X10X10 TN 39241/7 1.1 7 10 10 3350 3400 32000
8 K 8X11X8 TN 29241/8 1.1 8 11 8 3000 2900 30000
K 8X11X10 TN 39241/8 1.7 8 11 10 3830 3950 30000
K 8X11X13 TN 49241/8 1.8 8 11 13 5000 5700 30000
K 8X12X10 TN 29242/8 1.3 8 12 10 4900 4600 30000
9 K 9X12X10 TN 39241/9 1.5 9 12 10 4200 4700 30000
K 9X12X13 TN 19241/9 1.9 9 12 13 5500 6700 30000
10 K 10X13X10TN 39241/10 1.6 10 13 10 4500 5250 27000
K 10X13X13 TN 39241/10 2.1 10 13 13 6000 7600 27000
K 10X13X16 TN   2.2 10 13 16 6300 7800 27000
K 10X14X10 TN 29242/10 2.9 10 14 10 7000 7900 27000
K 10X14X13 TN 3922/10 4.3 10 14 13 8000 9100 26000
K 10X16X12 TN 19244/10 3.7 10 16 12 7000 9300 27000
12 K 12X15X9 TN   2.7 12 15 9 4120 5210 25000
K 12X15X10 TN 39241/12 1.9 12 15 10 4320 5730 25000
K 12X15X13 TN 49241/12 2.4 12 15 13 6000 8100 25000
K 12X16X8 TN 19242/12 2.9 12 16 8 1200 4700 25000
K 12X16X10 TN 29242/12 3.4 12 16 10 6000 6900 25000
K 12X16X13 TN 39242/12 3.8 12 16 13 7900 9200 25000
K 12X17X13 TN 59242/12 4.4 12 17 13 9300 10000 24000
K 12X18X12 TN 19244/12 5 12 18 12 9800 8000 24000
K 12X15X20 TN K12X15X 20TN 3.8 12 15 20 8200 12000 25000
14 K 14X17X10   4 14 17 10 5100 6800 23000
K 14X17X17   6.8 14 17 17 9300 14000 23000
K 14X18X10 29242/14 4.8 14 18 10 6800 8300 23000
K 14X18X13 39242/14 6.3 14 18 13 8100 9800 23000
K 14X18X14   6.8 14 18 14 9200 12000 23000
K 14X18X15 49242/14 7.3 14 18 15 10000 13000 23000
14 K 14X18X17 59242/14 8.1 14 18 17 10500 13900 23000
K 14X20X12 19243/14 8.6 14 20 12 9900 10500 22000
15 K 15X18X14   5.3 15 18 14 7500 11000 23000
K 15X18X17   6.4 15 18 17 9600 15900 23000
K 15X19X10 29242/15 5.1 15 19 10 7200 9000 22000
K 15X19X13 39241/15 7 15 19 13 8300 9800 22000
K 15X19X17 59241/15 8.8 15 19 17 10300 15000 22000
K 15X19X24 ZW 79241/15 10.5 15 19 24 12800 20100 22000
K 15X22X13 29242/15 8.9 15 22 13 9700 11000 22000
K 15X22X12 19243/15 10 15 22 12 10000 13000 22000
K 15X21X15 39242/15 13 15 21 15 13800 16000 22000
K 15X21X21   18.2 15 21 21 18000 24000 22000
16 K 16X20X10 29241/16 5.7 16 20 10 7600 9700 22000
K 16X20X13 39241/16 7.1 16 20 13 8700 11300 22000
K 16X20X17 59241/16 9.2 16 20 17 11200 16300 22000
K 16X21X10 19242/16 3.7 16 21 10 9000 12000 22000
K 16X22X12 19243/16 10.4 16 22 12 11000 12000 21000
K 16X22X13   11.9 16 22 13 12000 13400 21000
K 16X22X16   13.7 16 22 16 14300 17000 21000
K 16X22X20 49243/16 16.7 16 22 20 18000 22300 21000
K 16X23X14 19244/16 20 16 23 14 19000 21000 19000
K 16X24X20 19245/16 24.9 16 24 20 21100 23000 20000
17 K 17X21X10 29241/17 5.6 17 21 10 7900 10100 21000
K 17X21X13 39241/17 7.5 17 21 13 10000 14100 21000
K 17X21X17 59241/17 9.5 17 21 17 12000 17400 21000
K 17X23X14 29243/17 11.5 17 23 14 11000 15000 21000
18 K 18X22X10 29241/18 6.1 18 22 10 8200 9900 20000
K 18X22X13 39241/18 7.7 18 22 13 9000 12100 20000
K 18X22X17 59241/18 10.8 18 22 17 11900 17600 20000
K 18X24X12 19243/18 11.6 18 24 12 11200 12900 20000
K 18X24X13   12.6 18 24 13 12900 14900 20000
K 18X24X13.5   13 18 24 13.5 12900 14900 20000
K 18X24X20 49243/18 19 18 24 20 20000 26500 20000
K 18X25X14   14.9 18 25 14 16500 18800 20000
K 18X25X22   24.3 18 25 22 22900 28400 20000
K 18X26X14   19 18 26 14 18000 20000 18000
K 18X 8X16 19244/18 24 18 28 16 19000 18400 19000
19 K 19X23X13   8.2 19 23 13 9300 13000 20000
K 19X23X17   11.1 19 23 17 12000 18600 20000
20 K 20X24X10 29241/20 6.5 20 24 10 8700 12100 19000
K 20X24X12   8 20 24 12 9600 13800 19000
K 20X24X13 39241/20 8.9 20 24 13 9600 13800 19000
K 20X24X17 59241/20 11.2 20 24 17 12400 20000 19000
K 20X26X12 19243/20 13.2 20 26 12 13100 15700 19000
K 20X26X16 K9249/20 17.5 20 26 16 18000 25000 18500
K 20X26X17 39243/20 18.2 20 26 17 18700 25500 19000
K 20X26X20 49243/20 22 20 26 20 20600 28500 19000
K 20X28X20 19245/20 26.8 20 28 20 23400 28000 18000
K 20X28X25 29245/20 36.2 20 28 25 30000 28500 18000
K 20X30X30 39245/20 56 20 30 30 35000 41000 18000
21 K 21X25X13   9 21 25 13 9600 14500 19000
K 21X25X17   12 21 25 17 12800 21000 19000
22 K 22X26X10 29241/22 7.1 22 26 10 8700 12900 18000
K 22X26X13 39241/22 9.4 22 26 13 10000 15400 18000
K 22X26X17 59241/22 12.1 22 26 17 13100 22100 18000
K 22X27X13 29242/22 10.8 22 27 13 14000 23000 18000
K 22X28X17 39243/22 19.7 22 28 17 19000 26500 18000
K 22X28X23 59243/22 26 22 28 23 20000 27000 19000
K 22X29X16 19244/22 22.2 22 29 16 19500 25000 17000
K 22X30X15 TN   14.4 22 30 15 19600 22900 17000
K 22X30X20 19245/22 28 22 30 20 21000 23500 18900
K 22X32X24   43.4 22 32 24 33500 39500 16000
23 K 23X35X16 TN   30 23 35 16 24000 23400 15000
24 K 24X28X10   8.1 24 28 10 9400 14300 17000
K 24X28X13   10.1 24 28 13 10500 17000 17000
K 24X28X17 9243/24 13.2 24 28 17 14000 24500 17000
K 24X29X13   13.5 24 29 13 13100 19100 16000
K 24X30X17   21.5 24 30 17 19000 27000 16000
K 24X30X31   39.1 24 30 31 27000 43000 16000
25 K 25X29X10 29241/25 8.3 25 29 10 9700 14900 16000
K 25X29X13 39241/25 10.4 25 29 13 10800 17900 16000
K 25X29X17 59241/25 13.7 25 29 17 14500 25500 16000
K 25X30X13 29242/25 12.9 25 30 13 14100 21300 16000
K 25X30X20 59242/25 20.5 25 30 20 21100 28000 16000
K 25X30X25   21 25 30 25 21700 40400 15000
K 25X30X26 52436/25 21.6 25 30 26 20100 26500 15000
K 25X31X17 39243/25 21.8 25 31 17 19000 28000 16000
K 25X31X21 39243/25 26.2 25 31 21 24100 37500 16000



Single Row Radial Needle Roller Bearing K 10X13X10 TN Polymide Cage

Single Row Radial Needle Roller Bearing K 10X13X10 TN Polymide Cage



Single Row Radial Needle Roller Bearing K 10X13X10 TN Polymide Cage
